Part no.: 99 3412 282 03
M8 Female angled panel mount connector, Contacts: 3, unshielded, THR, IP67, UL
M8, series 718, Automation Technology - Sensors and Actuators
General features
MorelessPart no. | 99 3412 282 03 |
Connector design | Female angled panel mount connector |
Type standard | DIN EN 61076-2-104 |
Version | Connector socket straight |
Connector locking system | screw |
Termination | THR |
Degree of protection | IP67 |
Temperature range from/to | -40 °C / 85 °C |
Mechanical operation | > 100 Mating cycles |
Weight (g) | 3.38 |
Customs tariff number | 85369010 |
Country of Origin | DE |
Electrical parameters
MorelessRated voltage | 60 V |
Rated impulse voltage | 1500 V |
Rated current | 4.0 A |
Pollution degree | 3 |
Overvoltage category | II |
Insulating material group | II |
EMC compliance | unshielded |
Material
MorelessContact body material | PA |
Contact material | CuSn (bronze) |
Contact plating | Au (gold) |
REACH SVHC |
CAS 7439-92-1 (Lead) |
SCIP number | 32a9f7dc-0f8d-4980-b790-de9709ade407 |
Authorization/approvals
MorelessApprovals | UL |
Classifications
MorelesseCl@ss 11.1 | 27-44-01-02 |
ETIM 9.0 | EC002635 |
Security notices
- The connectors have been developed for applications in plant engineering, control and electrical equipment construction. The user is responsible for checking whether the connectors can also be used in other areas of application.
- Plug connectors with enclosure protection IP67 and IP68 are not suitable for use under water. When used outdoors, the plug connectors must be protected separately against corrosion. For further information on the IP protection classes, please refer to the "Technical Information" download centre.
