  4. Snap-In Twin distributor, Y-distributor, Contacts: 5, unshielded, pluggable, IP67, UL, VDE
Part no.: 79 9180 000 05

Snap-In Twin distributor, Y-distributor, Contacts: 5, unshielded, pluggable, IP67, UL, VDE

Snap-In IP67, series 720, Miniature Connectors
Available numbers of contacts
Compare product
Downloads
General features
Moreless
Part no. 79 9180 000 05
Connector design Twin distributor, Y-distributor
Version Twin distributors
Connector locking system snap-in
Termination pluggable
Degree of protection IP67
Temperature range from/to -25 °C / 85 °C
Mechanical operation > 500 Mating cycles
Weight (g) 35.00
Customs tariff number 85444290
Country of Origin DE
Rated voltage 125 V
Rated impulse voltage 1500 V
Rated current 5.0 A
Pollution degree 2
Overvoltage category II
Insulating material group II
EMC compliance unshielded
Housing material PA
Contact body material PA
Contact material CuZn (brass) / CuSn (bronze)
Contact plating Au (gold)
REACH SVHC CAS 7439-92-1 (Lead)
SCIP number 460ef7e0-98cf-4528-8d33-25548338545a
eCl@ss 11.1 27-06-03-11
ETIM 9.0 EC002638
Low Voltage Directive 2014/35/EU (EN 60204-1:2018;EN 60529:1991)
RoHS Directive 2011/65/EU (EN 50581:2012)
Security notices
  1. The connector must not be plugged or unplugged under load. Non-observance and improper use can result in personal injury.
  2. The connectors have been developed for applications in plant engineering, control and electrical equipment construction. The user is responsible for checking whether the connectors can also be used in other areas of application.
  3. Plug connectors with enclosure protection IP67 and IP68 are not suitable for use under water. When used outdoors, the plug connectors must be protected separately against corrosion. For further information on the IP protection classes, please refer to the "Technical Information" download centre.
