  4. Push-Pull Male panel mount connector, Contacts: 3, unshielded, solder, IP67, front fastened
Part no.: 09 4907 080 03

Push-Pull Male panel mount connector, Contacts: 3, unshielded, solder, IP67, front fastened

Push Pull, series 430, Subminiature Connectors
Available numbers of contacts
Compare product
Downloads
General features
Moreless
Part no. 09 4907 080 03
Connector design Male panel mount connector
Version Connector pin straight
Connector locking system Push-Pull
Termination solder
Degree of protection IP67
Cross-sectional area 0.25 mm² / AWG 24
Temperature range from/to -40 °C / 85 °C
Mechanical operation > 500 Mating cycles
Weight (g) 10.03
Customs tariff number 85369010
Rated voltage 125 V
Rated impulse voltage 1500 V
Rated current (40 °C) 4.0 A
Pollution degree 2
Overvoltage category I
Insulating material group II
EMC compliance unshielded
Contact body material PUR/PA
Contact material CuZn (brass)
Contact plating Au (gold)
REACH SVHC CAS 7439-92-1 (Lead)
SCIP number a9170eb5-b5f9-4bd6-84a5-7f3c00ca4cac
eCl@ss 11.1 27-44-01-09
ETIM 7.0 EC003569
Security notices
  1. The connector must not be plugged or unplugged under load. Non-observance and improper use can result in personal injury.
  2. The connectors have been developed for applications in plant engineering, control and electrical equipment construction. The user is responsible for checking whether the connectors can also be used in other areas of application.
  3. Connectors which are used in circuits with voltages dangerous to the touch may only be installed and used by, or under the supervision of, persons with electrical engineering training, taking into account the applicable regulations and standards.
  4. Plug connectors with enclosure protection IP67 and IP68 are not suitable for use under water. When used outdoors, the plug connectors must be protected separately against corrosion. For further information on the IP protection classes, please refer to the "Technical Information" download centre.
