  4. M8 Female panel mount connector, Contacts: 3, unshielded, THT, IP67, M12x1.0, front fastened
Part no.: 86 6518 1123 00003

M8 Female panel mount connector, Contacts: 3, unshielded, THT, IP67, M12x1.0, front fastened

M8, series 718, Automation Technology - Sensors and Actuators
Available numbers of contacts
Compare product
Downloads
General features
Moreless
Part no. 86 6518 1123 00003
Alternative part no.: 09 3412 80 03
Notice
Please note that, due to the change from the old to the new order number, there may be deviations in the technical specifications. For questions about product details, please use the ‘Contact Customer Service’ form on the right.
More
Connector design Female panel mount connector
Type standard DIN EN 61076-2-104
Version Connector socket straight
Connector locking system screw
Termination THT
Degree of protection IP67
Temperature range from/to -40 °C / 85 °C
Mechanical operation > 100 Mating cycles
Weight (g) 11.68
Customs tariff number 85369010
Country of Origin DE
Rated voltage 60 V
Rated impulse voltage 1500 V
Rated current 4.0 A
Pollution degree 3
Overvoltage category II
Insulating material group II
EMC compliance unshielded
Housing material CuZn (Brass nickel plated)
Contact body material PA black
Contact material CuSn (bronze)
Contact plating Au (gold)
Contact length 9.5 mm
REACH SVHC CAS 7439-92-1 (Lead)
SCIP number 73a2546f-0fc3-4138-887a-ac7d5e929ee2
eCl@ss 11.1 27-44-01-09
ETIM 9.0 EC003569
Security notices
  1. The connectors have been developed for applications in plant engineering, control and electrical equipment construction. The user is responsible for checking whether the connectors can also be used in other areas of application.
  2. Plug connectors with enclosure protection IP67 and IP68 are not suitable for use under water. When used outdoors, the plug connectors must be protected separately against corrosion. For further information on the IP protection classes, please refer to the "Technical Information" download centre.
