  4. Snap-In Female panel mount connector, Contacts: 5, unshielded, THT, IP40
Part no.: 09 9792 20 05

Snap-In Female panel mount connector, Contacts: 5, unshielded, THT, IP40

Snap-In IP40, series 719, Subminiature Connectors
Available numbers of contacts
Compare product
Downloads
General features
Moreless
Part no. 09 9792 20 05
Connector design Female panel mount connector
Version Connector socket straight
Connector locking system snap-in
Termination THT
Degree of protection IP40
Temperature range from/to -25 °C / 70 °C
Mechanical operation > 100 Mating cycles
Weight (g) 1.38
Customs tariff number 85369010
Country of Origin DE
Rated voltage 60 V
Rated impulse voltage 800 V
Rated current 3,0 A
Insulation resistance ≥ 1010 Ω
Pollution degree 1
Overvoltage category II
Insulating material group III
EMC compliance unshielded
Housing material PA
Contact body material PA
Contact material CuSn (bronze)
Contact plating Au (gold)
REACH SVHC CAS 7439-92-1 (Lead)
SCIP number b44a59ed-7145-4887-9c96-f35a50887f84
eCl@ss 11.1 27-44-01-09
ETIM 9.0 EC003569
Security notices
  1. The connectors have been developed for applications in plant engineering, control and electrical equipment construction. The user is responsible for checking whether the connectors can also be used in other areas of application.
