Part no.: 09 0431 703 04
M12 Male receptacle, Contacts: 4, shielded, THR, IP68 plugged and locked, Front mounting, angled, for centered PCB mounting
M12-A, series 713, Automation Technology - Sensors and Actuators
General features
Moreless| Part no. | 09 0431 703 04 |
| Connector design | Male receptacle |
| Type standard | DIN EN 61076-2-101 |
| Connector locking system | screw |
| Termination | THR |
| Degree of protection | IP68 plugged and locked |
| Temperature range from/to | -40 °C / 85 °C |
| Mechanical operation | > 100 Mating cycles |
| Weight (g) | 0.00 |
| Customs tariff number | 85369010 |
Electrical parameters
Moreless| Rated voltage | 250 V |
| Rated impulse voltage | 1500 V |
| EMC compliance | shielded |
Material
Moreless| Contact body material | LCP (UL94 V-0) |
| Contact material | CuZn (brass lead-free) |
| Contact plating | Au (gold) |
| SCIP number | SCIP-number not available |
